| SKU:
GCL100-80C
Bosch | GCL100-80C 12V Max Connected Cross-Line Laser with Plumb Points
Bosch | GCL100-80C 12V Max Connected Cross-Line Laser with Plumb Points is backordered and will ship as soon as it is back in stock.
Couldn't load pickup availability
12V Max Connected Cross-Line Laser with Plumb Points
Includes:
The Bosch GCL100-80C 12 V Max Connected Cross-Line Laser with Plumb Points delivers all-in-one versatility, with highly visible lines and points. They provide horizontal level, vertical alignment and plumb point transfer applications. The tool features Bosch-exclusive VisiMax technology, which monitors tool temperature and power consumption to deliver the brightest line for the job.. The laser features Bosch 12 V Max Lithium-ion power for extended laser runtime during complex or all day layout jobs, provides a visible range of 100 Ft. and can work with an optional Bosch laser receiver to extend that range to 165 Ft. The Smart Pendulum System self-levels up to +/-4 degrees, indicates out-of-level condition and locks for safe tool transport. The manual mode locks lines for use at any angle. The laser comes with the RM 2 Magnetic Rotating Mount that rotates 360 degrees, has a micro-fine adjustment knob and includes a ceiling grid clip.
- Accuracy: Laser lines: +/- 1/8 @ 30 ft; Laser points: +/-9/32 @ 30 ft
- Battery Voltage: 12
- Height: 4.8"
- Laser Diode: Class 2, 630 - 650 nm
- Length: 5.4"
- Leveling Type: Self-Leveling, Up to 4 degrees
- Material: Plastic with over-mold
- Mount Threading: 1/4-20
- Operating Temperature: 14 degrees F / -10 degrees C ~1 22 degrees F / 50 degrees C
- Range: Up to 100-ft
- Weight: 1.4lb
- Width: 2.2"
- Includes: (1) GCL100-80C 12V Max Connected Cross-Line Laser with Plumb Points, (1) RM 2 Mount, (1) 12V Max Battery, (1) 12V Max Charger, (1) Ceiling Grid Clip, (1) Laser Target Plate, (1) Heavy-Duty Pouch, (1) Hard Carrying Case
- All-in-one functionality - facilitates one-person job setup with horizontal leveling, vertical alignment and plumb point transfer applications, connected capability, Li-ion battery technology and long working range
- Built In. VisiMax technology - delivers maximum beam brightness, optimized energy efficiency and long-term tool reliability
- Bosch Leveling Remote App - free to download and free to use, this app turns the leveling laser on and off, selects the laser operating modes, adjusts line visibility and provides battery and level alerts
- 12 V Max Lithium-Ion power - features long runtime for complex or all-day layout jobs
- Bright laser lines - has a visible range of 100 Ft. with an accuracy of +/-1/8 In. at 30 Ft. for confidence in the job setup
- Pulse receiver mode - use an optional laser receiver (LR 6 or LR8) for applications with a 165 Ft. working range
- Smart Pendulum System - self levels, indicates out-of-level condition, and locks pendulum for safe transport
Specifications
| Power Source | Cordless |
|---|---|
| Product Type | Line Lasers |
| Laser Color | Red |
