| SKU:
05006622001
WERA Kraftform Kompakt VDE GO RA 3
WERA Kraftform Kompakt VDE GO RA 3 is backordered and will ship as soon as it is back in stock.
Couldn't load pickup availability
WERA Kraftform Kompakt VDE GO RA 3
The Wera Kraftform Kompakt VDE GO RA 3 (05006622001) is a 5-piece insulated screwdriver set supplied in a compact belt-mounted holster. The set includes one 837 i RA blade-holding screwdriver with ratchet functionality and four interchangeable Kraftform Kompakt VDE blades featuring square-head and slotted profiles.
The 837 i RA screwdriver features a fine-tooth ratchet mechanism with 40 teeth and a 9° return angle, allowing screwdriving without having to reposition the tool. The ratchet mechanism also allows fast spinning during screwdriving. The screwdriver features a 9 mm hex drive with an entry chamfer.
The compact holster attaches to a belt using a rear loop, keeping the tools readily accessible during mobile use. Its design allows the handle to be removed and the required blade inserted using one hand. Strong rubber-band loops securely hold the handle and four VDE blades.
The interchangeable blades feature reduced shaft diameters (iS) with integrated protective insulation, allowing access to recessed screws and spring elements. Wera's Take it easy tool finder uses colour coding by profile and laser-engraved size markings for blade identification. The tools are individually tested in accordance with IEC 60900 for work at the approved voltage of 1,000 V.
What's Included
- 1 × 837 i RA Kraftform Ratcheting Blade-Holding Handle, 115 mm (05057490001)
- 1 × Kraftform Kompakt VDE 68 iS Square-Head #1 Blade, 157 mm (05006545001)
- 1 × Kraftform Kompakt VDE 68 iS Square-Head #2 Blade, 157 mm (05006546001)
- 1 × Kraftform Kompakt VDE 60 iS Slotted 0.6 × 3.5 mm Blade, 157 mm (05006506001)
- 1 × Kraftform Kompakt VDE 60 iS Slotted 1.0 × 5.5 mm Blade, 157 mm (05006508001)
- 1 × 9594 Kraftform Kompakt VDE GO RA Belt Holster, 74 × 167 mm (05136423001)
- 1 × Hook-and-Loop Fastener Strip, 50 × 70 mm
- 5-Piece VDE Tool Set – Includes one 837 i RA ratcheting blade-holding handle and four interchangeable VDE blades.
- 40-Tooth Ratchet Mechanism – Fine-tooth ratchet with a 9° return angle allows screwdriving without repositioning the tool.
- One-Handed Blade Changes – Holster design allows the handle to be removed and the required blade inserted using one hand.
- Belt-Mounted Holster – Rear belt loop keeps tools readily accessible during mobile use.
- Secure Tool Storage – Strong rubber-band loops securely hold the screwdriver handle and four VDE blades.
- VDE Insulated Tools – Individually tested in accordance with IEC 60900 for work at the approved voltage of 1,000 V.
- Reduced-Diameter Blades – Integrated protective insulation and reduced shaft diameter allow access to recessed screws and spring elements.
- Take it easy Tool Finder – Colour-coded profiles and laser-engraved size markings help identify the required blade.
- Square-Head and Slotted Blades – Includes square-head #1 and #2, plus slotted 0.6 × 3.5 mm and 1.0 × 5.5 mm blades.
- 9 mm Hex Drive – Features an entry chamfer for the interchangeable blade system.
Specifications
| Specification | Details |
|---|---|
| Brand | Wera |
| Part Number | 05006622001 |
| Product Name | Kraftform Kompakt VDE GO RA 3 |
| Number of Pieces | 5 |
| Screwdriver Handle | 837 i RA Kraftform |
| Handle Function | Ratchet |
| Ratchet Teeth | 40 |
| Return Angle | 9° |
| Drive | 9 mm Hex with Entry Chamfer |
| Interchangeable Blades | 4 |
| Blade Profiles | Square-Head #1 / Square-Head #2 / Slotted 0.6 × 3.5 mm / Slotted 1.0 × 5.5 mm |
| Blade Length | 157 mm |
| Handle Length | 115 mm |
| Blade Shaft | Reduced Diameter (iS) |
| Tool Finder | Take it easy |
| VDE Standard | IEC 60900 |
| Approved Working Voltage | 1,000 V |
| Holster | 9594 Kraftform Kompakt VDE GO RA |
| Holster Size | 74 × 167 mm |
| Size | 175 × 90 × 60 mm |
| Weight | 342 g |
| Country of Origin | CZ |
| EAN | 4013288238665 |
